P84 Series Power Take-off
Interpump Hydraulics' P84 Series PTO is applicable on Volvo i-Shift, Mack m-Drive, and Eaton HD/XD Endurant transmissions.
• Mechanically shifted through-shaft PTO
• Driveline and direct mount pump applications
• DIN and SAE outputs
• Includes adapter and stud kit
-
Rear mount PTOs in North AmericaAndrew Dawson – Director of Product Management and Marketing
| PTO TORQUE & HORSEPOWER RATINGS | ||||
| PTO SERIES | INTERMITTENT HP (kW) @ 1,000 RPM | INTERMITTENT TORQUE LBS.FT. (Nm) | ENGINE % | SPEED RATIO |
| RS4S-P84Z-2 | 57 (44) | 300 (406) | 177 | 1.29:1 |
| RS4S-P84Z-4 | 70 (42) | 369 (500) | 126 | .92:1 |
| Approximate Weight: 21 lbs. (9.53 Kg.) | ||||
 |
||||
The Muncie Power Take-Off is warranted to be free of defects in material or workmanship and to meet Muncie’s standard written specifications at the time of sale. Muncie’s obligation and liability under this warranty is expressly limited to repairing or replacing, at Muncie’s option, within one year (two years on Allison World Transmission PTOs) after date of original installation any defective part or parts or any product not meeting the specifications.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED. MUNCIE MAKES NO WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR ANY PARTICULAR PURPOSE. MUNCIE’S OBLIGATION UNDER THIS WARRANTY SHALL NOT INCLUDE ANY TRANSPORTATION CHARGES OR COSTS OF INSTALLATION OR ANY LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR DELAY. THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE, AND MUNCIE’S LIABILITY WITH RESPECT TO ANY CONTRACT OR SALE OR ANYTHING DONE IN CONNECTION THEREWITH, WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, OR OTHERWISE, SHALL NOT, EXCEPT AS EXPRESSLY PROVIDED HEREIN, EXCEED THE PRICE OF THE PRODUCT OR PART ON WHICH SUCH LIABILITY IS BASED.
If requested by Muncie, products or parts for which a warranty claim is made are to be returned transportation prepaid to a Muncie Service Center. Any installation or use not in accordance with catalog or package instructions, other improper use, operation beyond capacity, substitution of parts not approved by Muncie, use with equipment other than the equipment on which the Power Take-Off is first installed, or alteration or repair made to the Power Take-Off other than at a Muncie Service Center, shall void this warranty. No employee or representative of Muncie is authorized to change this warranty in any way or to grant any other warranty.
| MODEL NUMBER CONSTRUCTION | |
   |
