Interpump Hypress 1SC TFEM01K Hose

APPLICATIONS:

Agriculture, Cranes, Forklifts, Construction, Mobile Hydraulics, Industrial Hydraulics, Earth Moving

TYPE APPROVAL:

MSHA, ABS.

APPLICABLE SPECS:

Exceeds EN 857 1SC - ISO 11237 1SC



No-Skive hose. Burst pressure exceeds EN standards. Impulse tested up to 2x EN standard.



Hose Assembly Form Contact Us

Internal hose: Synthetic rubber, extruded whole without joints, of uniform thickness.

Reinforcement: 1 high tensile steel wire braid.

Covering: Anti-abrasive synthetic rubber, resistant to oils, fuels and atmospheric conditions.

Recommended fluid: Mineral and biological oils, glycol-water based, water, lubricants.

Operating temperature: -40°F to +248°F (-40°C to +120°C) Continuous; -40°F to +275°F (-40°C to +135°C) Intermittent; -40°F to +158°F (-40°C to +70°C) for water based fluids; +32°F to +158°F (0°C to +70°C) for water.
