Tow & Recovery
-
CS10/CS11 Series Power Take-Off
Constructed with large gears, the CS10 Series PTO is built for heavy duty applications. The CS10 features a drag brake and an output shaft designed around popular hydraulic pumps. For a more compact installation, the CS11 is a remotely mounted solenoid option.
Max Torque
500 lbs.ft.
Max HP (@1000 RPM)
95 HP
Weight
68 lbs.
-
CS24/CS25 Series Power Take-Off
Designed with the same technology as the CS10 Series, the CS24 Series PTO is 20 percent smaller. CS PTOs are engaged by means of a direct mounted solenoid, which activates an internal wet clutch pack. With this feature, installation is made simple with a single hose connection
Max Torque
325 lbs.ft.
Max HP (@1000 RPM)
62 HP
Weight
52 lbs.
-
CS6/CS8 Series Power Take-Off
Designed to work on Allison 1000 and 2000 series automatics and many other current manual transmissions, the CS6/8 Series PTOs offer direct mount pump options and a drag brake. Upgrading to a multi-disk clutch brake allows for absolute shaft stoppage.
Max Torque
350 lbs.ft.
Max HP (@1000 RPM)
67 HP
Weight
47 lbs.
-
FR/FA Series Power Take-Off
The FR and FA Series power take-offs were designed in cooperation with Ford Motor Company's engineers to fit the 5R110 "TorqShift®" and 4R100 automatic transmissions.
1998-2004 F250-F550 (Gas or Diesel) with 4R100
2005-2016 F250-F550 (Gas) with 5R110
2005-2010 F250-F550 (Diesel) with 5R110 -
FR66 SERIES Power Take-Off
Muncie’s updated FR66 power take-off gives you the versatility of mounting larger hydraulic pumps to handle a variety of heavy duty jobs. Our PTO utilizes a one-piece housing design with forced lubrication for increased durability and simplified installation. The FR66 incorporates integral mobile or stationary functions and a higher torque capacity of 200 lbs.ft.
2011-Present F250-F550 (Diesel) with 6R140
2017-Present F250-F550 (Gas) with 6R140
2016-Present F650-F750 (Diesel) with 6R140
2013-Present F650-F750 (Gas) with 6R140Max Torque
200 lbs.ft.
Max HP (@1000 RPM)
39 HP
-
PF Series Gear Pump
Ultimate power and performance in a small package best describes the F4 Series gear pumps. The pressure balanced bushing blocks and sleeve bearings provide both long life and high performance.
Displacement (Cu.In./Rev)
.24 - 2.01
GPM (@1000 RPM)*
1 - 8.7
Max Pressure
3,625 PSI
*Flow rates are theoretical.
-
PH Series Clutch Pumps
Muncie clutch pumps provide hydraulic power at the flip of a switch. Clutch pumps can be used in situations where a PTO aperture is unavailable or difficult to access. Although normally belt driven, clutch pumps may also be shaft driven from the engine crankshaft.
Displacement (Cu.In./Rev)
.62 - 2.96
GPM (@1000 RPM)*
2.7 - 12.8
Max Pressure
3,500 PSI
*Flow rates are theoretical.
-
TG Series Power Take-Off
As the most versatile and widely used double gear type power take-off in the industry, the TG Series is available with 10 speed ratios, 19 shift types, 19 output shaft options and input gears for all popular transmissions.
Max Torque
285 lbs.ft.
Max HP (@1000 RPM)
54 HP
Weight
22 lbs.
-
V080 Directional Control Valve
The V080 is constructed with high grade iron castings and nickel-plated spools for use in high pressure applications and can be configured with many different spool, control, and positioner options. The V080 is designed for flow rates up to 30 GPM (114 LPM), and offers superior performance in a compact package. Muncie Power Products takes pride in supplying the highest quality products along with outstanding service & support.
Flow Capacity (Nominal)
21 GPM (80 LPM)
Flow Capacity (Maximum)
30 GPM (114 LPM)
Max Pressure (1-3 Sections)
5,075 PSI (350 BAR)
Max Pressure (4-6 Sections)
4,650 PSI (320 BAR)
Max Pressure (7-10 Sections)
4,350 PSI (300 BAR)
-
V130 Directional Control Valve
The V130 is constructed with high grade iron castings and nickel-plated spools for use in high pressure applications and can be configured with many different spool, control, and positioner options. The V130 is designed for flow rates up to 55 GPM (208 LPM), and offers superior performance in a compact package. Muncie Power Products takes pride in supplying the highest quality products along with outstanding service & support.
Flow Capacity (Nominal)
34 GPM (130 LPM)
Flow Capacity (Maximum)
55 GPM (208 LPM)
Max Pressure (1-3 Sections)
5,440 PSI (375 BAR)
Max Pressure (4-6 Sections)
5,075 PSI (350 BAR)
Max Pressure (7-10 Sections)
4,710 PSI (325 BAR)
